Device Maintenance

The device supports multiple methods to copy version images onto the target device for upgrading.

The Device Copies the Image as a TFTP Client

In this scenario, the device and a file server establish communication. The device functions as a TFTP client, while the file server operates as a TFTP server. The objective is to download the version image stored on the server to the device, thereby accomplishing the software version upgrade.

1. Configure the IP address of the file server, ensuring that the file server and the device are routable.
2. Start the TFTP server on the device to initiate the download of the version image.

admin@sonic:~$ tftp
tftp> help
tftp> connect
(to) 150.1.0.1
tftp> get AsterNOS-V5.2R001.bin
Received 17437 bytes in 0.0 seconds
tftp> quit
admin@sonic:~$ ls
AsterNOS-V5.2R001.bin

Copying Images Using SCP

1. Configure the IP address of the file server to ensure that the file server and the device are reachable via routing.
2. On the device, use the SCP command to complete the download of the version image.

admin@sonic:~$ sudo scp server@192.168.0.100:/share/ AsterNOS-V5.2R001.bin
admin@sonic:~$ ls
AsterNOS-V5.2R001.bin

Copying Images Using a USB Drive

This method is suitable when there is no network environment available, and you need to copy the version image to the device. Typically, the USB port of the device is located on the front panel.

1. Insert the USB drive containing the system image into the device’s USB port.
2. Execute a command to view the disk name corresponding to the USB drive:

admin@sonic:\~$ sudo /sbin/fdisk -l

3. Create a directory for mounting the USB drive.

admin@sonic:\~$ sudo mkdir /mnt/usb/

4. Mount the USB drive. Take the example of /dev/sdb4 as the path for the USB drive, but please adjust according to the actual situation.

admin@sonic:\~$ sudo mount /dev/sdb4 /mnt/usb

5. Navigate to the directory of the mounted disk and copy files from the disk to the device.

admin@sonic:~$ cd /mnt/usb
admin@sonic:/mnt/usb/$ sudo cp AsterNOS-V5.2R001.bin /home/admin
admin@sonic:~$ ls
AsterNOS-V5.2R001.bin

Executing the Upgrade Command

Operation	Command	Description
Execute the upgrade command	image update image-name	If a configuration upgrade is required, please execute the “write” command to save the configuration before proceeding with the upgrade. Once the upgrade is completed without any errors, you’ll need to manually restart the device to switch to the new version
Display the version	show version	-

Version rollback

When there are multiple available image versions in the current system, the device supports version rollback.

First, use the sonic_installer list command to check the currently available versions on the device:

sonic# system bash
Use 'exit' to return sonic-cli
admin@sonic:~$ sudo sonic_installer list
Current: SONiC-OS-V5.2R015-20251230.203457      # Current version
Next: SONiC-OS-V5.2R015-20251230.203457         # The version to be used at the next startup
Available:
SONiC-OS-V5.2R015-20251230.203457           # Available versions
SONiC-OS-V5.2R015T06-20251226.151841        # Available versions

According to the output of “sonic_installer list”, there are two available image versions on the device. The default startup item is the currently running version (V5.2R015-20251230.203457). It is possible to roll back to the other version (V5.2R015T06-20251226.151841).

Users can roll back the version using the set_default command, setting the version for the next startup to V5.2R015T06-20251226.151841.

admin@sonic:\~$ sudo sonic_installer set_default SONiC-OS- V5.2R015T06-20251226.151841

Verification:

admin@sonic:~$ sudo sonic_installer list
Current: SONiC-OS-V5.2R015-20251230.203457      # Current version
Next: SONiC-OS-V5.2R015T06-20251226.151841      # The version to be used at the next startup
Available:
SONiC-OS-V5.2R015-20251230.203457           # Available versions
SONiC-OS-V5.2R015T06-20251226.151841        # Available versions

Restart to apply changes

admin@sonic:\~$ sudo reboot

In this way, the rolled-back version will be started.

One-click Collection of Operation and Maintenance Information

When operation and maintenance personnel remotely troubleshoot on-site faults, they often need to communicate multiple times to check the configuration status of on-site switches. To facilitate collecting more information at one time, a quick operation and maintenance command is added to collect switch information. After executing this command, the compressed file is saved to the fixed directory /var/dump/, which can be copied.

admin@sonic:\~$ show techsupport

The switch allows users to collect logs and core files from a specified date onwards using “since”, or to specify the number of logs to collect using “count”.

For example:

admin@sonic:\~$ show techsupport --since 2026-01-16 count 2

System Memory-Monitor

This operation is used to enable the system memory protection mechanism of the switch. This mechanism monitors the system memory and the status of processes within the container in real-time. When an abnormality is detected, it automatically triggers hierarchical recovery operations (such as alarms, termination of non-critical processes). It aims to prevent the system from getting stuck due to memory exhaustion or process abnormalities and reduce the need for manual intervention.

After this function is enabled, the system will perform a memory status check every five minutes.

Caution

NOTE: This function is disabled by default and needs to be enabled manually.

Processing Method When Memory Exceeds the Threshold

• If a single process exceeds 30%, the system outputs an alarm log.。
• If a single process exceeds 50%, the system outputs an alarm log. If the process is a non-critical process, the system automatically terminates it; if it is a critical process, only an alarm is issued without termination.。
• When the total memory exceeds 80%, the system outputs an alarm log.
• When the total memory exceeds 95%, the system outputs an alarm log. It automatically terminates the current non-critical process with the highest memory usage (Top 1). If the process is a critical process, it will not be terminated.

Configuration Method

Enable global memory monitoring and automatic processing functions.

sonic# configure
sonic(config)# system memory-monitor kill-process-enable

Turn off the global memory monitoring and automatic processing functions.

sonic# configure
sonic(config)# no system memory-monitor kill-process-enable

Bandwidth Utilization Exceeds Threshold Alarm

This operation is used to set bandwidth alarms for specified interfaces. When the utilization rate exceeds the set threshold, the system will generate an alarm log; when the utilization rate drops below the recovery threshold, the alarm will be cleared.

1. Enter the configuration view of the specified interface.

You need to first enter the interface view you want to configure (for example, Ethernet2)

sonic# configure
sonic(config)# interface ethernet 2
sonic(config-if-2)#

2. Configure alarm thresholds

In the interface view, use the log-threshold command for configuration. You can set both incoming and outgoing directions (both) at the same time, or set the outgoing direction (tx) or incoming direction (rx) separately.

Command format:log-threshold direction alert_threshold resume_threshold

sonic(config-if-2)#log-threshold both 70 60

After the configuration is completed, you can use the show command to check the global default values and the custom alarm configurations on all interfaces.

Run the following command directly in the privileged EXEC mode (sonic#):

sonic# show interface log-threshold
Interface Default Bandwidth utilization rx/tx alert_threshold: 80%, resume_threshold: 75%
  customer defined
  Interface      rx_alert_threshold    rx_resume_threshold    tx_alert_threshold    tx_resume_threshold
  -----------   --------------------  ---------------------  --------------------  ---------------------
  Ethernet2                     70                      60                   70                      60

License Explanation

Switches come with a default license in their factory settings. If you need to apply for a license, please visit the Asterfusion help website (https://help.cloudswit.ch/portal/en/newticket ) for support.

Users can check the device’s license status using “show license status”.

sonic# show license status
License Name : all-19710101-license
MD5 : fab126157378dd632cc607d0c00488cd
Valid : True
Build Time : 1970-12-31 16:07:24
Valid To : 2026-07-19 09:39:08
Feature        Status
---------------------------------------
IGMP          TRUE
TUNNEL          TRUE
ROUTER_PROTOCOL      TRUE
CLI                TRUE

Vailid To：The valid time of the device’s license. If the switch’s license expires, users are allowed to enter the system configuration view but cannot configure IGMP, TUNNEL, ROUTE_PROTOCOL, etc. (Existing relevant configurations will still take effect but cannot be modified.)

Feature：Features controlled by License

• IGMP：Valid value TRUE/FALSE, indicating whether the multicast function (IGMP Snooping) is enabled.
• TUNNEL：Valid value TRUE/FALSE, indicating whether the tunnel function (GRE, VXLAN) is enabled
• ROUTE_PROTOCOL：Valid values are TRUE/FALSE, indicating whether the routing policy functions (BGP, OSPF) are enabled.
• CLI：The valid values are TRUE/FALSE, indicating whether the command line is enabled. If it is not enabled, you cannot enter the system configuration view.

License Usage

When a device needs to apply a newly obtained license file, the file should be placed in the /etc/sonic/lic directory of the switch.

admin@sonic:~ $ sudo cp path/ sn-time-license /etc/sonic/lic

Verification:

sonic# system bash
Use 'exit' to return sonic-cli
admin@sonic:~$ cd /etc/sonic/lic
admin@sonic:/etc/sonic/lic$ ls
sn-time-license

License Update

sonic# license update

Network Connectivity Check

Explanation of this section: The functions and standard operation methods of the two basic network diagnostic tools, Ping and Traceroute. The standard troubleshooting approach is: first use Ping to confirm connectivity and basic quality, and if a problem is found, then use Traceroute to locate the specific network node where the fault occurs.。

Ping

The ping command is used to test the network layer connectivity, round-trip delay, and stability between a local device and a target IP address or domain name. It is the first tool used in network troubleshooting.

In the device’s command-line interface, executing the ping command requires specifying the target address and supports users to append optional parameters as needed.

sonic# ping 192.168.0.1
  source           Source IP-address (ip) or interface (ip and arp) or vrf
  repeat           Requests to send count, default is 5
  resolve          Resolve names
  broadcast        Ping broadcast address
  size             Packet size
  interval         The time interval between packets, default is 1
  flood            Flood ping

Interpretation of execution results

Output/Phenomenon	Possible causes and key points for troubleshooting
Destination Host Unreachable	ICMP destination unreachable, replied by intermediate routing devices (usually gateways). It indicates that the gateway knows how to reply, but the route to the destination does not exist or ARP fails. Check the switch’s default route and gateway ARP table (show arp)
Request timeout	1. One-way traffic failure: The outgoing or incoming path is blocked.
2. The peer or intermediate device drops ICMP: Common in security policies.
3. Severe routing black hole. Action: Immediately execute traceroute or use the -I option to change the source address for testing to identify the interruption point.
Unknown host	DNS resolution failed. Check SONiC’s DNS configuration: cat /etc/resolv.conf, and try pinging the IP address directly to distinguish whether it is a network issue or a DNS issue.
large avg/max or large mdev	Network congestion, poor link quality, or circuitous paths. It is necessary to check the delay of each hop using traceroute.
Intermittent packet loss	It may be caused by link fluctuations, unstable ARP tables, or queue congestion. Use ping -c 100 for continuous testing. Check the error packet counts and logs of relevant interfaces on SONiC (show logging).

Traceroute

The Traceroute command is used to discover and display the complete path (each hop router) that data packets take from the source device to the target host, and to measure the delay to each hop. When the network is unavailable or the delay is too high, it can accurately locate the network node where the fault occurs.

In the device command line, enter Traceroute followed by the target address.

sonic# traceroute 192.168.15.81
  resolve  Resolve names
  source   Source IP-address

****Interpretation of execution results

** Output/Phenomenon **	** Possible causes and key points for troubleshooting **
* * *	Timeout. Try switching the -T or -I protocol.
**!H / !N **	The host/network is unreachable. The router clearly indicates that there is no route. Check the hop device.
**!X / !A **	Management policy prohibits/communication rejected. Explicitly blocked by security devices (ACL, firewall).
** Sudden increase in delay **	The current hop or the previous hop has network congestion or a poor path. Further analysis is needed in combination with the topology.
** The end of the path is reachable, but the application is not accessible **	The path is normal; the problem may be at the application layer (service not listening, higher-level firewall).
